Agilent Technologies 6811B User Manual

Verification and Calibration - B
69
Table B-2. Agilent 6811B Verification Test Record
Model Agilent 6811B Report No.____________Date_____________
Test Description Minimum
Specification
Recorded Results Maximum
Specification
Voltage Programming and Measurement Accuracy
300 Vrms accuracy at 45 Hz
Front Panel Measurement
300 Vrms accuracy at 400 Hz
Front Panel Measurement
300 Vrms accuracy at 1 kHz
Front Panel Measurement
299.250 V
Vrms
−
190 mV
298.200 V
Vrms
−
190 mV
296.700 V
Vrms
−
400 mV
_______V
_______V
_______V
_______V
_______V
_______V
300.750 V
Vrms +190 mV
301.800 V
Vrms +190 mV
303.300 V
Vrms +400 mV
DC Programming and Measurement Accuracy
425 Vdc accuracy
Front Panel Measurement
−
425 Vdc accuracy
Front Panel Measurement
424.075 V
Vdc
−
0.277 V
−
424.075 V
Vdc
−
0.277 V
_______V
_______V
_______V
_______V
425.925 V
Vrms +0.277 V
−
425.925 V
Vrms +0.277 V
RMS Current Measurement Accuracy
Low Range
High Range
(Iout = calculated output current @ 60Hz)
Iout
−
0.0039 A
Iout
−
0.0095 A
_______A
_______A
Iout +0.0039 A
Iout +0.0095 A
Table B-3. Agilent 6812B Verification Test Record
Model Agilent ______________________ Report No.____________ Date_____________
Test Description Minimum
Specification
Recorded Results Maximum
Specification
Voltage Programming and Measurement Accuracy
300 Vrms accuracy at 45 Hz
Front Panel Measurement
300 Vrms accuracy at 400 Hz
Front Panel Measurement
300 Vrms accuracy at 1 kHz
Front Panel Measurement
299.250 V
Vrms −190 mV
298.200 V
Vrms −190 mV
296.700 V
Vrms −400 mV
_______V
_______V
_______V
_______V
_______V
_______V
300.750 V
Vrms +190 mV
301.800 V
Vrms +190 mV
303.300 V
Vrms +400 mV
