Agilent Technologies 81101A Reference Guide

27
Programming Reference
Agilent 81101A SCPI Command Summary
:OUTPut[1]
[:NORMal]
[:STATe]
OFF|ON|1|0 Set/read normal output state
:IMPedance
47
[:INTernal]
<value> Set/read internal source impedance of
output
:EXTernal
<value> Set/read expected external load imped-
ance at output
47
:POLarity
NORM|INV Set/read output polarity
48
[:SOURce]
:CURRent[1]
[:LEVel]
[:IMMediate]
[:AMPLitude]
<value> Set/read channel amplitude current
48
:OFFSet
<value> Set/read channel offset current
49
:HIGH
<value> Set/read channel high level current
50
:LOW
<value> Set/read channel low level current
51
:LIMit
[:HIGH]
Set/read maximum current limits
52
:LOW
Set/read minimum current limits
53
:STATe
ON|OFF|1|0 Enable/Disable the current limits
53
:FREQency
[:CW | :FIXed]
<value> Set/read frequency of pulses
54
:AUTO
ONCE Measure frequency at CLK-IN
55
:HOLD[1]
VOLT|CURR Switch between VOLtage and CURRent
command subtrees
55
:PHASe[1]
[:ADJust]
<value> Set/read channel phase
56
:PULSe
:DCYCLe[1]
<value> Set/read channel duty cycle
57
:DELay[1]
<value> Set/read channel delay (to leading edge)
57
:HOLD
TIME|PRATio Hold absolute delay|phase delay fixed
with varying frequency
58
:UNIT
S|SEC|PCT|DEG|RAD Set/read delay units
59
Command Parameter Description
see
page
