Agilent Technologies 81101A Reference Guide

32
Programming Reference
Default Values, Standard Settings
:LOW –10.0mA
:STATe OFF
:FREQ [:CW|:FIXed] 1.00MHz
:AUTO not applicable
:HOLD VOLT
:PHASe[1][:ADJust] 0.0
:PULSe:
:DCYCle[1] 10.0% (derived from Width and Period)
:DELay[1] 0.0
:HOLD TIME
:UNIT S
:DOUBle[1][:STATe] OFF
:DELay 250 ns
:HOLD TIME
:UNIT S
:HOLD[1] WIDTh
[:SOURce]:PULSe:PERiod 1
µ
s
:AUTO not applicable
:TDELay[1] 100ns
:TRANsition[1|2]:HOLD TIME
:UNIT S
[:LEADing] 5.0 ns
:TRAiling 5.0 ns
:AUTO ON
:TRIGger[1]:VOLTage TTL
:WIDTh[1] 100ns
:ROSCillator:SOURce INTernal
:EXTernal:FREQ 5MHz
Parameter *RST, Default Values
