Triggering - The TRIGger Subsystem Measurement Operations & Settings
Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Fifth Edition 171
Triggering - The TRIGger
Subsystem
The TRIGger Subsystem allows you to configure how the instrument
reacts to incoming or outgoing triggers.
Table 8 Triggering and Power Measurements
Hardware
Triggering
Trigger Rearming Software Triggering Data Acquisition Functions
sens:func:stat
trig:inp trig:inp:rearm init:imm init:cont MINMax LOGGing|STABility
IGNore - One power mea-
surement is per-
formed.
Automatically performs power
measurements.
Automatically performs power
measurements until the func-
tion is finished.
SMEasure ON Every hardware trigger starts a new power measure-
ment.
Every hardware trigger starts a
new power measurement until
the function is finished.
CMEasure ON The first hardware trigger starts
the function. Subsequent pow-
er measurements are automati-
cally performed until the
function is finished.
SMEasure OFF The first hardware trigger starts a new power mea-
surement. Further hardware triggers are ignored until
you send trig:inp:rearm again.
Every hardware trigger starts a
new power measurement until
the function is finished.
CMEasure OFF The first hardware trigger starts
the function. Subsequent pow-
er measurements are automati-
cally performed until the
function is finished.
