Mass Storage, Display, and Print Functions Display Operations – The DISPlay Subsystem

188 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Fifth Edition

command:

:DISPlay:LOCKout?

syntax: :DISPlay:LOCKout?

description: Queries whether local operation is locked out.

parameters: none

response: A boolean value: 0 – local operation is disabled

1 – local operation is enabled.

example: disp:lock → 1<END>
