360 Chapter6
Programming Command Cross Reference
Programming Command Versus Front Panel Key
PSTATE SAVELOCK ON OFF Protects saved states (save lock).
RCLS RECALL STATE Recalls previously saved state
(RC).
RCLT RECALL TO TRA
RECALL TO TRB
Recalls specified trace data.
SAVES PWR ON STATE
SAVE STATE
Savescurrentstateoftheanalyzer
in the specified register (SV).
SAVET SAVE TO TRA
SAVE TO TRB
Saves specified trace data.
SERVICE
REQUEST
RQS Specifies the decimal weighing of
status byte bits that are allowed
during service request. RQS is set
to 0 with power-up or device clear.
SRQ Setsservice request if operand bits
are allowed by RQS.
STB Returns the decimal equivalent of
the bits set in the status byte.
SPAN FS FULL SPAN Specifies the full frequency span
for the spectrum analyzer.
SP SPAN ZERO SPAN Specifies the frequency span.
SWEEP CONTS SWEEP CONT SGL
(CONT)
Selects continuous sweep mode
(S1).
DLYSWP DLY SWP [ ] DLY SWP ON
OFF
Delays the start of the sweep until
the specified time elapses after the
trigger event (or before the trigger
event with Option 007).
GATE GATE ON OFF Turns on or off the time-gating
function.
GATECTL GATE CTL EDGE LVL Selects between the edge and the
level mode for time-gate function.
GD GATE DLY [ ] Sets the delay time from when the
gate trigger occurs to when the
gate is turned on.
GL GATE LEN [ ] Sets the length of time the time
gate is turned on.
GP EDGE POL POS NEG LVL
POL POS NEG
Sets the polarity (positive or
negative) for the gate trigger.
MEAS Queries whether the instrument is
sweeping continuously, or a single
time.
SNGLS SWEEP CONT SGL (SGL) Selects single sweep mode (S2).
ST SWP TIME AUTO MAN Specifies sweep time.
TS Takes a sweep.
SYNCHRONI-
ZATION
DONE Returns a 1 when task has been
completed.
TS Takes a sweep.
Table 6-2 Programming Command Functional Index
Function
Category
Command Corresponding Key
Function
Description
