Programming Command Cross Reference
Programming Command Versus Front Panel Key
TRACE DET DETECTOR MODES Specifies video detector type.
TRACE MATH AMB A−B→A ON OFF A − B into A (C1 and C2).
AMBPL A−B+DL→A ON OFF A − B + DL into A.
APB A+B → A A + B into A.
AXB A EXCH B Exchanges A and B (EX).
BML B−DL → B B − DL into B (BL).
TRACE
PROCESSING
BLANK BLANK A BLANK B Stores and blanks specified trace
register (A4 and B4).
CLRW CLEAR WRITE A CLEAR
WRITE B
Clear-writes specified trace
register (A1 and B1).
MINH Holds the minimum trace register
values.
MXMH MAX HOLD A
MAX HOLD B
Max-holds the specified trace
register (A2 and B2).
NORMLIZE NORMLIZE ON OFF Activates normalization routine.
NRL NORM REF LVL Sets the normalized reference
level.
RCLT RECALL TO TRA
RECALL TO TRB
Recalls specified trace data.
SAVET SAVE TO TRA
SAVE TO TRB
Saves specified trace data.
TRA Selects input and output of trace
A.
TRB Selects input and output of trace
B.
VAVG VID AVG ON OFF Turns video averaging on or off.
VIEW VIEW A
VIEW B
Views specified trace register (A3
and B3).
TRIGGER CONTS SWEEP CONT SGL
(CONT)
Selects continuous sweep mode
(S1).
SNGLS SWEEP CONT SGL (SGL) Selects single sweep mode (S2).
TM FREE RUN VIDEO LINE
EXTERNAL
Selects trigger mode: free run(T1),
video (T4), line (T2), external (T3).
TRIGPOL TRIG POL POS NEG Selects the edge (positive or
negative) of the trigger input that
causes the trigger event.
VTL VIDEO Video trigger level.
Table 6-2 Programming Command Functional Index
