7-7

Calibration Commands

MODule:OWAVelength

130 OUTPUT 707;":CALIBRATE:CONTINUE"

140 OUTPUT 707;":CALIBRATE:SDONE?"

150 ENTER 707;Prompt$ <Done>

160 END

MODule:OWAVelength

Command :CALibrate:MODule:OWAVelength <wavelength>

This command sets the optical wavelength for an optical channel calibration. This command

should only be used for modules with an optical channel.

Example 10 OUTPUT 707;":CALIBRATE:MODULE:OWAVELENGTH 1340E–9"

MODule:STATus?

Query :CALibrate:MODule:STATus?{LMODule | RMODule}

This query returns the status of the module calibration (electrical and optical channels) and

optical calibration (optical channels) as either CALIBRATED or UNCALIBRATED. It will

return UNKNOWN if the module does not have calibration capability. Queries to modules

with two electrical channels (including TDR modules) will return the status of module cali-

bration only. Queries to modules with two optical channels will return the status of the mod-

ule calibration, followed by the status of optical calibration of the first channel, followed by

the status of the optical calibration of the second channel.

Returned Format [:CALibrate:MODule:STATus] {<status vertical calibration>,<status optical calibration> | CALIBRATED |

UNCALIBRATED | UNKNOWN} <NL>

MODule:TIME?

Query :CALibrate:MODule:TIME? {LMODule | RMODule | CHANnel <N>}

The query returns the date and time at the last channel module calibration, and the differ-

ence between the current channel temperature and the temperature of the channel when it

was last calibrated. If there is not a module in the selected slot, the message “Empty Slot” is

returned. <N> is an integer, from 1 to 4.

NOTE This query is for a module calibration only.

Returned Format [:CALibrate:MODule:TIME] <value><NL>

<value> Is in the format: DD MMM YY HH:MM <delta_temp>

<delta_temp> Is the difference between the current temperature and the temperature when the last cali-

bration was done. For example, <delta_temp> might be:

–5C

10C

–12C

MODule:VERTical

Command :CALibrate:MODule:VERTical {LMODule | RMODule | CHANnel<N> | SLOT<N> }
