18
N1010A FlexDCA and 86100A/B/C/D
Firmware Release Notes
• Waveform Signal Processing functionality is now available from a new, translucent
slide- up panel accessed via the new Math button in the lower right- hand corner
of the application.
• Annotations have been added to the upper right- hand corner of the Jitter
Measurement Results window to denote large jitter mode (LJM) and jitter
measurements on signal processed waveforms (SP).
General Defects Fixed
• Fixed a bug that allowed multiple conflicting instances of FlexDCA to be launched
at the same time.
• Improved the performance of Jitter Mode on long patterns.
• Improved the reliability of autoscale.
• Fixed an alignment issue with certain masks.
• Fixed a defect that prevented pattern waveform saves from remembering the last
saved location.
• Fixed a defect that could, under certain conditions, result in an empty
measurement toolbar after the application had been manually resized.
• Fixed a defect that could cause the application to crash if a jitter graph in an
undocked window was double- clicked.
• Fixed a bug that prevented jitter measurements from being made on a function
of a waveform memory (partial results only).
• Added annotation to the RJ and RN measurements when the values are fixed by
the user.
• Fixed a limit tests defect in Jitter Mode. Limit tests now report out- of- limit
failures.
• Fixed a defect that prevented a remote FlexDCA session from being able to end
a different active FlexDCA session that is connected to the same 86100 DCA.
A.12.02 Release Notes, May, 2013 (Differences from Release A.12.00)
General Comments
• Improvements added to eye measurement algorithms.
