7
Verification kit
85055A 8719/8720 only: 0.045 to 18 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables
Use the test port cables recommended for devices
with 7 mm connectors, and 7 mm to Type-N adapters
that are from the 85054B/D Type-N calibration kit
(see 7 mm connector section).
Adapter set
85130C 8719/8720 only: 3.5 mm
1
to Type-N
For devices with 2.4 mm connectors
Calibration kits
85056A standard: 0.045 to 50 GHz. Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
00915-60003 2.4 mm (m) sliding load
00915-60004 2.4 mm (f) sliding load
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
85056D economy: 0.045 to 50 GHz. Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
Verification kit
85057B 8722 only: 0.045 to 50 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for the 8722ET/ES
85133C single, semi-rigid: 2.4 mm, 81 cm, 32 inches
85133D set, semi-rigid: 2.4 mm, 53 cm each, 21 inches
85133E single, flexible: 2.4 mm, 81 cm, 32 inches
85133F set, flexible: 2.4 mm, 53 cm each, 21 inches
Adapter set
85130G 8722 only: 2.4 mm
1
to 2.4 mm
For devices with K connectors (2.92 mm)
Calibration kit
85056K
2
economy, 2.92/2.4 mm: 0.045 to 40 GHz.
Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
00915-60003 2.4 mm (m) sliding load
00915-60004 2.4 mm (f) sliding load
11904-60001 2.4 mm (m) to 2.92 mm (m) adapter
11904-60002 2.4 mm (f) to 2.92 mm (f) adapter
11904-60003 2.4 mm (m) to 2.92 mm (f) adapter
11904-60004 2.4 mm (f) to 2.92 mm (m) adapter
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
Option 001 adds 2.4 mm sliding loads and gages
Cables
3
85133C single, semi-rigid: 2.4 mm, 81 cm, 32 inches
85133D set, semi-rigid: 2.4 mm, 53 cm each, 21 inches
85133E single, flexible: 2.4 mm, 81 cm, 32 inches
85133F set, flexible: 2.4 mm, 53 cm each, 21 inches
Adapters
11904A 2.4 mm (m) to K (m)
11904B 2.4 mm (f) to K (f)
11904C 2.4 mm (m) to K (f)
11904D 2.4 mm (f) to K (m)
11904S 2.4 mm to K adapter set
For devices with 7-16 connectors
Calibration kits
85038A standard: 30 kHz to 7.5 GHz. Includes:
85038-80002 7-16 (f) open
85038-80003 7-16 (m) open
85038-80004 7-16 (f) short
85038-80005 7-16 (m) short
85038-80006 7-16 (f) fixed load
85038-80007 7-16 (m) fixed load
8710-2175 torque wrench
8710-2174 open-end wrench
85038F economy: 30 kHz to 7.5 GHz. Includes:
85038-80002 7-16 (f) open
85038-80004 7-16 (f) short
85038-80006 7-16 (f) fixed load
11906-80016 7-16 (f) to 7-16 (f) adapter
1. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.
2. This kit can be used to calibrate in the 2.4 mm interface, as well as measure
in the 2.92 mm (K connector).
3. 2.4 mm to K type adapters are required in addition to these cables.
