9
Power meters
1
E4418B EPM series, single channel
E4419B EPM series, dual channel
Power sensors
8481B 10 MHz to 18 GHz, Type-N (m), 25 watt
8482B 100 kHz to 4.2 GHz, Type-N (m), 25 watt
8485A 50 MHz to 26.5 GHz, APC-3.5 mm (m), 100 mW
8481A 10 MHz to 18 GHz, Type-N (m), 100 mW
8482A 100 kHz to 4.2 GHz, Type-N (m), 100 mW
8483A 100 kHz to 2 GHz, Type-N (m), 75 ohm, 100 mW
R8486A 26 GHz to 40 GHz, waveguide flange UG-599/U,
100 mW
8487A 50 MHz to 50 GHz, 2.4 mm (m), 100 mW
Power amplifiers
2
83006A 0.01 to 26.5 GHz, 20 dB gain, power out:
+18 dBm to 10 GHz or +16 dBm to 20 GHz or
+14 dBm to 26.5 GHz
83017A 0.05 to 26.5 GHz, 25 dB gain, power out:
+20 dBm to 20 GHz or +15 dBm to 26.5 GHz
83018A 2 to 26.5 GHz, 27 dB gain to 20 GHz or 23 dB
to 26.5 GHz, power out: +24 dBm to 20 GHz or
+21 dBm to 26.5 GHz
83020A 2 to 26.5 GHz, 30 dB gain to 20 GHz or 27 dB
to 26.5 GHz, power out: +30 dBm to 20 GHz or
+26 dBm to 26.5 GHz
83050A 2 to 50 GHz, 23 dB gain, power out:
+20 dBm to 40 GHz or +17 dBm to 50 GHz
83051A pre-amplifier, 0.045 to 50 GHz, 23 dB gain,
power out: +12 dBm to 45 GHz or +10 dBm to 50 GHz
Couplers
87300B coaxial: 1 to 20 GHz, SMA (f), 10 dB coupling
87300C coaxial: 1 to 26.5 GHz, 3.5 mm (f), 10 dB
coupling
87301D coaxial: 1 to 40 GHz, 2.4 mm (f) or optional
2.92 mm (f), 13 dB coupling
87310B 90° coaxial: 1 to 18 GHz, SMA (f), 3 dB
coupling
87301E coaxial: 2 to 50 GHz, 2.4 mm (f), 10 dB
coupling
Test fixtures
For TRL/LRM and TOSL calibration standards,
microstrip adapters, and test fixtures, Agilent recom-
mends ICM
3
adjustable test fixture mainframe series
TF-3000, which is compatible with the ICM TRL-3000
series calibration kits.
Bias supplies
4
6626A precision DC power supply; 2 A, 50 V maximum
6629A quad-out precision GPIB DC power supply
4142B modular DC source/monitor; 10 A, 200 V
maximum
Bias networks
5
11590B 100 MHz to 12.4 GHz, Type-N, 0.5 A and 100 V
maximum bias
Option 001 100 MHz to 18 GHz, 7 mm, 0.5 A and 100
V maximum bias
11612A 45 MHz to 26.5 GHz, 3.5 mm (f), 0.5 A and 40 V
maximum bias
Option 001 2 A maximum bias
11612B 45 MHz to 50 GHz, 2.4 mm (f), 0.5 A maximum
bias
System software
85070C high-temperature dielectric probe kit.
Includes the dielectric probe, software on 3.5 inch
disk, cables, port/cable adapters, switch, short cir-
cuit, mounting bracket, adapters, 50-ohm termination,
stand, vials, and stoppers. Measures complex permit-
tivity of materials. Standard software version runs
on PC with Windows® 95, 98, or NT 4.0.
85071C materials measurement software.
Measures complex permeability and permittivity
of materials in a transmission line environment.
Software runs on a PC with Windows® 95, 98, or
NT 4.0.
85190A IC-CAP modeling suite
6
Design Software, Advanced Design System series
(ADS) and Series IV
6
connector repair kits
Application support
Agilent 50629E productivity assistance; provides one
hour of on-site consulting and assistance delivered
by an application engineer. Hourly charges apply
from portal to portal to cover travel costs.
Test Configuration Accessories
1. A power meter with the appropriate Agilent 8480 series power sensor is required
for use with the power meter calibration feature.
2. RF connectors: 3.5 mm (f) on RF input and output; BNC (f) detector out. 2.4 mm (f)
on RF input and output for 85050A, 83051A.
3. Inter-Continental Microwave, 1515 Wyatt Drive, Santa Clara, CA 95054-1524,
Telephone: (408) 727-1596
Fax: (408) 727-0105
4. For internally biasing with the 8719ES/8720ES/8722ES.
5. For supplying DC bias externally from test sets. Internal bias networks have
a current limit of 0.5 A.
6. Consult with an Agilent systems application engineer. The product you order
will depend on the test environment.
