Agilent Technologies 8719ET Configuration Guide

8
85038M economy: 30 kHz to 7.5 GHz. Includes:
85038-80003 7-16 (m) open
85038-80005 7-16 (m) short
85038-80007 7-16 (m) fixed load
11906-80015 7-16 (m) to 7-16 (m) adapter
Electronic calibration kit
85098B RF ECal:
1
30 kHz to 7.5 GHz. Includes:
85098-60005 7-16 (m) to 7-16 (f) RF ECal module
Option 00F substitutes:
85098-60007 7-16 (f) to 7-16 (f) RF ECal module
Option 00M substitutes:
85098-60006 7-16 (m) to 7-16 (m) RF ECal module
Option 00A adds:
11906-80015 7-16 (m) to 7-16 (m) adapter
11906-80016 7-16 (f) to 7-16 (f) adapter
Cables
Use the test port cables recommended for devices
with 7 mm, 3.5 mm, or Type-N connectors and use
the appropriate 11906 series adapter kit.
Adapter kits
11906A 7-16 to 7-16. Includes:
11906-80015 7-16 (m) to 7-16 (m) adapter
11906-80016 7-16 (f) to 7-16 (f) adapter
11906-80017 7-16 (m) to 7-16 (f) adapter (two included)
11906B 7-16 to Type-N. Includes:
11906-80007 Type-N (m) to 7-16 (m) adapter
11906-80008 Type-N (f) to 7-16 (f) adapter
11906-80009 Type-N (f) to 7-16 (m) adapter
11906-80010 Type-N (m) to 7-16 (f) adapter
11906C 7-16 to 7-mm. Includes:
11906-80012 7-mm to 7-16 (m) adapter (two included)
11906-80013 7-mm to 7-16 (f) adapter (two included)
11906D 7-16 to 3.5-mm. Includes:
11906-80002 3.5-mm (m) to 7-16 (m) adapter
11906-80005 3.5-mm (m) to 7-16 (f) adapter
11906-80004 3.5-mm (f) to 7-16 (m) adapter
11906-80003 3.5-mm (f) to 7-16 (f) adapter
For devices with waveguide
X Band
X11644A calibration kit (standard, WR-90, 8.2 to
12.4 GHz). Includes:
00896-60008 X-band standard section
00910-60003 X-band termination
11644-20018 X-band short
11644-20021 X-band shim (open)
X281C waveguide to 7 mm coax adapter
8719/8720: 85132F cable set (set, flexible, 7 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85135F cable set (set, flexible,
7 mm to 2.4 mm, 53 cm each, 21 inches)
X281C adapter (included in calibration kit):
WR-90 to 7 mm
P Band
P11644A calibration kit (standard, WR-62, 12.4 to
18 GHz). Includes:
00896-60007 P-band standard section
00910-60002 P-band termination
11644-20017 P-band short
11644-20020 P-band shim (open)
P281C waveguide to 7 mm coax adapter
8719/8720: 85132F cable set (flexible, 7 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85135F cable set (flexible, 7 mm to 2.4 mm,
53 cm each, 21 inches)
P281C adapter (included in calibration kit):
WR-62 to 7 mm
K Band
K11644A calibration kit (standard, WR-42, 18 to
26.5 GHz). Includes:
00896-60006 K-band standard section
00910-60001 K-band termination
11644-20016 K-band short
11644-20019 K-band shim (open)
K281C waveguide to 3.5 mm (f) coax adapter
8719/8720: 85131F cable set (set, flexible, 3.5 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85134F cable set (set, flexible, 3.5 mm to 2.4 mm,
53 cm each, 21 inches)
K281C adapter (included in calibration kit):
WR-42 to 3.5 mm (f)
Option 012 WR-42 to 3.5 mm (m)
R Band
R11644A calibration kit (standard, WR-28, 26.5 to
40 GHz). Includes:
00914-60028 R-band termination
11644-20005 R-band short
11644-20003 R-band shim (open)
11644-60001 R-band 10 cm straight waveguide
11644-60016 R-band 5 cm straight waveguide
8722: 85133F cable set (set, flexible, 2.4 mm, 53 cm
each, 21 inches)
R281A adapter (2.4 mm (f) to WR-28 waveguide
adapter)
R281B adapter (2.4 mm (m) to WR-28 waveguide
adapter)
Measurement Accessories, continued
1. Requires an Agilent 85097A ECal interface kit.
