S-parameter analyzer options
Some ES options cannot be ordered with other
options. See option compatibility table below.
007 mechanical transfer switch: replaces the solid-
state transfer switch with a mechanical trans-
fer switch. Increases test port power and
dynamic range by 5 dB.
010 time-domain capability: allows time-domain
measurements.
012 direct sampler access: configures the test set
with direct access to A and B sampler receiver
inputs. Operates as a standard instrument
with the jumpers installed.
085 high-power S-parameter test set modification:
deletes bias tees and adds a mechanical trans-
fer switch and internal attenuators. Allows
insertion of an amplifier before the transfer
switch and insertion of isolators in the meas-
urement configuration. Includes direct sam-
pler access (Option 012).
089 frequency offset mode: modifies the test set
and firmware. Provides mixer measurement
capability, allowing a receiver frequency offset
from the source.
1D5 high-stability frequency reference: replaces
standard frequency reference with a higher
stability unit.
400 adds fourth sampler and TRL calibration
firmware: replaces the transfer switch with
a solid-state switch/splitter.
The following options apply to both ET and ES
models:
Hardware options
1CM adds rack mount flange kit for use without
handles
1CP adds rack mount flange kit for use with
handles
1
Information options
0B0 deletes manual set
0B1 adds extra manual set
0BWadds service guide, part number 08720-90397
The following language options provide a translated
user’s guide:
ABF French manual, part number 5967-8509
ABJ Japanese manual, part number 5967-8503
Service options
W01 converts three year return-to-Agilent service
warranty to one year on-site service warranty.
2
W32 adds three years of return-to-Agilent calibration.
W34 adds three years of return-to-Agilent standards-
compliant calibration.
W52 adds five years of return-to-Agilent calibration.
W54 adds five years of return-to-Agilent standards-
compliant calibration.
Certification options
UK6 commercial calibration certification with
test data
1BN mil standard 45662A calibration certification
1BP mil standard 45662A calibration certification
with test data
Network Analyzer Options
S-Parameter Network Analyzer Option Compatibility
Option Option 1D5 Option 007 Option 010 Option 012 Option 085 Option 089 Option 400
1D5 High-stability frequency reference — Yes Yes Yes Yes Yes Yes
007 Mechanical transfer switch Yes — Yes Yes No
4
Yes No
3
010 Time domain Yes Yes — Yes Yes Yes Yes
012 Direct sampler access Yes Yes Yes — No
5
Yes Yes
085 High-power test Yes No
4
Yes No
5
—YesNo
3, 4
089 Frequency offset mode Yes Yes Yes Yes Yes — Yes
400 Four-sampler test set Yes No
3
Yes Yes No
3, 4
Yes ––
1. The 8720E family of network analyzers is supplied with handles.
2. Only where on-site service is available.
3. Option 400 uses solid-state switch splitter in place of transfer switch.
4. Option 085 requires and includes a mechanical transfer switch.
5. Option 085 includes direct sampler access (Option 012).
