Agilent Technologies 8720E Series Configuration Guide

6
For devices with 7 mm connectors
Calibration kits
85050B standard: 0.045 to 18 GHz. Includes:
00909-60008 7 mm coax termination
85050-60006 7 mm fixed broadband load
85050-80007 7 mm short
85050-80010 7 mm open
85050-80011 7 mm sliding load
85050C
1
precision TRL: 0.045 to 18 GHz. Includes:
00909-60008 7 mm coax termination
85050-60003 7 mm to 7 mm airline
85050-60005 7 mm to 7 mm TRL adapter
85050-60006 7 mm fixed broadband load
85050-80007 pin collet assembly
85050-80008 7 mm short
85050-80009 7 mm short collet
85050-80010 7 mm open
85050D economy: 0.045 to 18 GHz. Includes:
85050-60006 7 mm fixed broadband load
85050-80007 7 mm short
85050-80010 7 mm open
85031B economy: 30 kHz to 6 GHz. Includes:
00909-60008 7 mm coax termination
85050-60001 7 mm open/short
Electronic calibration kits
85091B RF ECal:
2
30 kHz to 9 GHz. Includes:
85091-60003 7 mm to 7 mm RF ECal module
85060B MW ECal:
2
1 GHz to 18 GHz. Includes:
85060-60002 7 mm to 7 mm MW ECal module
Option 001: adds a 30 kHz to 9 GHz RF ECal module
85091-60003 7 mm to 7 mm RF ECal module
Verification kit
85051B 8719/8720 only: 0.045 to 18 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for either 8719ET/ES or 8720ET/ES
85132C single, semi-rigid: 7 mm to 3.5 mm, 81 cm,
32 inches
85132D set, semi-rigid: 7 mm to 3.5 mm, 53 cm each,
21 inches
85132E single, flexible: 7 mm to 3.5 mm, 96 cm, 38 inches
85132F set, flexible: 7 mm to 3.5 mm, 53 cm each,
21 inches
Cables for the 8722ET/ES
85135C single, semi-rigid: 7 mm to 2.4 mm, 81 cm,
32 inches
85135D set, semi-rigid: 7 mm to 2.4 mm, 53 cm each,
21 inches
85135E single, flexible: 7 mm to 2.4 mm, 96 cm, 38 inches
85135F set, flexible: 7 mm to 2.4 mm, 53 cm each,
21 inches
Adapter sets
85130B 8719/20 only: 3.5 mm
3
to 7 mm
85130E 8722 only: 2.4 mm
3
to 7 mm
For devices with Type-N connectors
Calibration kits
85054B standard: 0.045 to 18 GHz. Includes:
00909-60011 Type-N (m) fixed lowband load
00909-60012 Type-N (f) fixed lowband load
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7 mm adapter
85054-60032 Type-N (m) to 7 mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-80010 Type-N (f) sliding load
85054-80009 Type-N (m) sliding load
85054-60050 Type-N (f) connector gage
85054-60052 Type-N (f) gage master
85054-60051 Type-N (m) connector gage
85054-60053 Type-N (m) gage master
Option K11 PSC-N slotless contact repair kit
85054D economy: 0.045 to 18 GHz. Includes:
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7 mm adapter
85054-60032 Type-N (m) to 7 mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-60046 Type-N (m) fixed load
85054-60047 Type-N (f) fixed load
Electronic calibration kits
85092B RF ECal:
2
30 kHz to 9 GHz. Includes:
85092-60005 Type-N (f) to Type-N (m) RF ECal module
Option 00M substitutes:
85092-60006 Type-N (m) to Type-N (m) RF ECal
module
Option 00F substitutes:
85092-60007 Type-N (f) to Type-N (f) RF ECal module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85064B MW ECal:
2
1 GHz to 18 GHz. Includes:
85064-60002 Type-N (f) to Type-N (m) MW ECal module
Option 00M substitutes:
85064-60004 Type-N (m) to Type-N (m) MW ECal
module
Option 00F substitutes:
85064-60006 Type-N (f) to Type-N (f) MW ECal
module
Option 001: adds a 30 kHz to 9 GHz RF ECal module
85092-60005 Type-N (f) to Type-N (m) RF ECal
module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
Measurement Accessories, continued
1. Kit includes open and short circuits, fixed loads, precision short airline,
7 mm connector tools, and gauges.
2. Requires an Agilent 85097A interface kit.
3. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.
