5
For devices with 3.5 mm or SMA connectors
Calibration kits
85052B standard: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
00911-60019 3.5 mm (m) sliding load
00911-60020 3.5 mm (f) sliding load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Option K11 PSC-3.5 slotless female center contact
repair kit
85052C
1
precision TRL: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
85052-60035 3.5 mm short TRL line
85052-60036 3.5 mm long TRL line
85052D economy: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85033D economy: DC to 6 GHz. Includes:
1250-1746 3.5 mm (f) to 7 mm adapter
1250-1747 3.5 mm (m) to 7 mm adapter
85033-60009 3.5 mm (m) load
85033-60010 3.5 mm (f) load
85033-60011 3.5 mm (m) open
85033-60012 3.5 mm (f) open
85033-60013 3.5 mm (m) short
85033-60014 3.5 mm (f) short
Option 001 deletes 3.5 mm to 7 mm adapters
Electronic calibration kits
85093B RF ECal:
2
30 kHz to 9 GHz. Includes:
85093-60005 3.5 mm (f) to 3.5 mm (m) RF ECal module
Option 00M substitutes:
85093-60006 3.5 mm (m) to 3.5 mm (m) RF ECal
module
Option 00F substitutes:
85093-60007 3.5 mm (f) to 3.5 mm (f) RF ECal
module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85062B MW ECal:
2
1 GHz to 26.5 GHz. Includes:
85062-60002 3.5 mm (f) to 3.5 mm (m) MW ECal
module
Option 00M substitutes:
85062-60004 3.5 mm (m) to 3.5 mm (m) MW ECal
module
Option 00F substitutes:
85062-60006 3.5 mm (f) to 3.5 mm (f) MW ECal
module
Option 001 adds:
a 30 kHz to 9 GHz RF ECal module
85093-60005 3.5 mm (f) to 3.5 mm (m) RF ECal
module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Verification kits
85053B 0.045 to 26.5 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for either 8719ET/ES or 8720ET/ES
85131C single, semi-rigid: 3.5 mm to 3.5 mm, 81 cm,
32 inches
85131D set, semi-rigid: 3.5 mm to 3.5 mm, 53 cm each,
21 inches
85131E single, flexible: 3.5 mm to 3.5 mm, 96 cm,
38 inches
85131F set, flexible: 3.5 mm to 3.5 mm, 53 cm each,
21 inches
Cables for the 8722ET/ES
85134C single, semi-rigid: 3.5 mm to 2.4 mm, 81 cm,
32 inches
85134D set, semi-rigid: 3.5 mm to 2.4 mm, 53 cm each,
21 inches
85134E single, flexible: 3.5 mm to 2.4 mm, 96 cm,
38 inches
85134F set, flexible: 3.5 mm to 2.4 mm, 53 cm each,
21 inches
Adapter sets
85130D 8719/8720 only: 3.5 mm
3
to 3.5 mm
85130F 8722 only: 2.4 mm
3
to 3.5 mm
1. Kit includes open and short circuits, fixed broadband loads, precision short
airlines, TRL adapters, and 3.5 mm connector tools.
2. Requires an Agilent 85097A interface kit.
3. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.
