Chapter 6 6-5
Error Reporting
Status Reporting
Table 6-3 Event Status Register B: Status Bit Definitions
Bit Name Definition
0 Single sweep, number of
groups, or calibration step
complete
A single sweep, group, or calibration step has been completed
since the last read of the register.
1 Service routine waiting or
done
An internal service routine has completed operation, or is
waiting for an operator response.
2 Data entry complete A terminator key has been pressed or a value entered over
GPIB since the last read of the register.
3 Limit failed, Channel 2 Limit test failed on Channel 2.
4 Limit failed, Channel 1 Limit test failed on Channel 1.
5 Search failed, Channel 2 A marker search was executed on Channel 2, but the target
value was not found.
6 Search failed, Channel 1 A marker search was executed on Channel 1, but the target
value was not found.
7 Copy Complete A copy has been completed since the last read of the register.
