6-15
Error Messages
Error Messages in Alphabetical Order
LOW PASS: FREQ LIMITS CHANGED
Information
Message
The frequency domain data points must be harmonically related from dc to the
stop frequency. That is, stop = n × start, where n = number of points. If this
condition is not true when a low pass mode (step or impulse) is selected and
transform is turned on, the analyzer resets the start and stop frequencies. The
stop frequency is set close to the entered stop frequency, and the start frequency
is set equal to stop/n.
MEMORY FOR CURRENT SEQUENCE IS FULL
Error Number
132
All the memory in the sequence you are modifying is filled with instrument
commands.
MORE SLIDES NEEDED
Error Number
71
When you use a sliding load (in a user-defined calibration kit), you must set at
least three slide positions to complete the calibration.
NO CALIBRATION CURRENTLY IN PROGRESS
Error Number
69
The softkey is not valid unless a calibration is
already in progress. Start a new calibration.
NO DISK MEDIUM IN DRIVE
Error Number
41
You have no disk in the current disk unit. Insert a disk, or check the disk unit
number stored in the analyzer.
NO FAIL FOUND
Service Error
Number 114
The self-diagnose function of the instrument operates on an internal test failure.
At this time, no failure has been detected.
NO FILE(S) FOUND ON DISK
Error Number
45
No files of the type created by an analyzer store operation were found on the
disk or the disk drive is empty. If you requested a specific file title, that file was
not found on the disk.
NO IF FOUND: CHECK R INPUT LEVEL
Error Number
5
The first IF signal was not detected during pretune. Check the front panel R
channel jumper. If there is no visible problem with the jumper, refer to the
service guide for troubleshooting.
