6-16
Error Messages
Error Messages in Alphabetical Order
NO LIMIT LINES DISPLAYED
Error Number
144
You can turn limit lines on but they cannot be displayed on polar or Smith chart
display formats.
NO MARKER DELTA - SPAN NOT SET
Error Number
15
You must turn the delta marker mode on, with at least two markers displayed,
in order to use the softkey function.
NO MEMORY AVAILABLE FOR INTERPOLATION
Error Number
123
You cannot perform interpolated error correction due to insufficient memory.
NO MEMORY AVAILABLE FOR SEQUENCING
Error Number
126
You cannot modify the sequence due to insufficient memory.
NO MODULE DATA FOR THIS PARAMETER
Information
Message
This message is displayed in Ecal service when there is no parameter data in
the ECal module.
NO PHASE LOCK: CHECK R INPUT LEVEL
Error Number
7
The first IF signal was detected at pretune, but phase lock could not be acquired.
Check the signal level to the R channel input to make sure it is −35 dBm or
higher. Refer to the service guide for troubleshooting.
NO SPACE FOR NEW CAL. CLEAR REGISTERS
Error Number
70
You cannot store a calibration set due to insufficient memory. You can free more
memory by clearing a saved instrument state from an internal register (which
may also delete an associated calibration set, if all the instrument states using
the calibration set have been deleted). You can store the saved instrument state
and calibration set to a disk before clearing them. After deleting the instrument
states, press to run the memory packer.
NO MODULE DATA FOR ISOLATION STD
Information
Message
This message is displayed in ECal service when there is no isolation data in the
ECal module.
NOT ALLOWED DURING POWER METER CAL
Error Number
198
When the analyzer is performing a power meter calibration, the GPIB bus is
unavailable for other functions such as printing or plotting.
→
