4
ESA-E Custom Confi guration – continued
Step 6. Add extra options
1
Description ESA-E spectrum analyzer EXA signal analyzer
Narrow resolution bandwidths
(recommended option)
Option 1DR Standard
Low-emissions shielding Option 060
2
Not available
Wide-offset phase noise improvement and
ACPR dynamic range extension
Option 120
3
Similar performance standard
Replace GPIB with serial port Option 1AX
3,4
Serial port unavailable; USB is standard
Time-gated spectrum analysis Options 1D6 Standard
50 Ω tracking generator Option 1DN, 9 kHz to 3 GHz Not available
Fast time domain sweep; IF, sweep,
and video output ports
Option AYX
3
Fast time domain sweep is standard
External mixing Option AYZ
5
Not available
Digital demodulation hardware Option B7D/B7E
6
Standard
APC 3.5 mm input connector Option BAB
5
Not available
Low frequency extension to 100 Hz Option UKB
7
Not available
EMI detectors and FM Demodulation Option AYQ
3,7
Most EMC adds quasi-peak deletion and basic FM
demodulation
1. If two or more ESA-E options are ordered, memory size may limit the number of options that may be loaded at any one time;
for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory
2. Not compatible with Option B7B
3. Requires one expansion slot
4. Not compatible with Option A4H
5. E4407B only
6. Requires Option 1D5; occupies two expansion slots, must be ordered jointly
7. Requires Option 1DR
