Installation Guide 9
E440xBU Option H70 Performance Test
Performance Test
Equipment
Gather the equipment listed in the following tables to verify the performance of the ESA
amplitude at the 70 MHz IF Out on the rear panel.
Table 3 Equipment List
Description Characteristics Model
Signal Source Equipment
Synthesized Sweeper Frequency: Must sweep 100 MHz
around 1 GHz Amplitude: −10 dBm
83620B
Analyzer Equipment
Spectrum Analyzer Upper Frequency Range: 2 GHz 8562E
8563E
Power Meter Equipment
Power Meter Absolute Accuracy: ±0.5%
Resolution: 0.01 dB
Reference Accuracy: 1.2%Power
Reference Accuracy: ±0.9%
Compatible with Agilent 8480 series
power sensors dB relative mode
E4419B
E4418A
Power Sensor Frequency Range: 1 MHz to 4.0 GHz
SWR at 50 MHz: ≤ 1.05
1 MHz to 4 GHz SWR: ≤ 1.22:1
Type-N (m), 50 Ω
8482A
8481A
Cables and Attenuators (as needed)
APC 3.5 (m)(m)
2 required
DC to 26.5 GHz
Length: ≤ 92 cm (36 in)
Insertion Loss: ~2 dB
8120-4921
SMA Low-loss, 1 meter 5064-5458
