Installation Guide 13
E440xBU Option H70 Performance Test
Measuring the Bandwidth of the IF Output
This test measures the ESA’s bandwidth at the 70 MHz output connector. A swept signal is
applied to the analyzer and the bandwidth is measured using another analyzer.
1. While the spectrum analyzer is still connected to the 70 MHz IF Output connector on
the rear of the ESA, configure the ESA and test equipment as follows:
Table 8 E440xBU ESA Signal Analyzer Setup
Parameter Setting
Center Frequency 1 GHz
Span 0 Hz
Resolution Bandwidth 1 MHz
Attenuation
0 dB
1
1. Choose 0 dB, this setting will determine the IF Out
level, with respect to the input signal.
Frequency Reference Internal
Table 9 Bandwidth Measurement Spectrum Analyzer Setup
Parameter Settings
Center Frequency 70 MHz
Span 100 MHz
Res BW 3 MHz
Reference Level 0 dBm
Log Scale 5 dB/Div.
Trace Max Hold
Table 10 Synthesized Sweeper Setup
Parameter Settings
Start Frequency 950 MHz
Stop Frequency 1050 MHz
Function CW or Sine
Level –10 dBm
To Next Page
