12 Installation Guide
E440xBU Option H70 Performance Test
7. Disconnect the power sensor from the cable and connect the cable directly to the ESA
RF Input.
NOTE If the ESA has Option BAB (APC 3.5 Input connector), use an
APC 3.5 (f) to N (f) adapter between the ESA and the Type-N cable.
8. Connect the 70 MHz IF Out on the rear panel of the ESA to the RF Input on the
spectrum analyzer. Use an SMA or APC 3.5 cable and appropriate adapters as needed.
9. Initialize the spectrum analyzer parameters as follows on Table 7.
10.Record the amplitude of the 70 MHz Output. The signal level should be –16 dBm
(±2 dB). This equates to a 6 dB loss between the RF Input and the 70 MHz Output port.
Table 7 70 MHz Measurement Spectrum Analyzer Settings
Parameter Setting
Center Frequency 70 MHz
Span 5 MHz
Resolution Bandwidth 1 MHz
Reference Level 0 dBm
Log Scale 5 dB/Div
