Chapter 1 23
Overview
Service Equipment You Will Need
10-Conductor Ribbon Cable (3 ea.) E4440-60071 To extend front end
driver board (Atten A,
Atten B, YTO).
26-Conductor Ribbon Cable E4440-60072 To extend front end
driver board (Lowband).
14-Conductor Ribbon Cable E4440-60337 To extend front end
driver board (RYTHM).
SMA Cable (Flexible) 5062-2662
To extend 2
nd
LO and
Sampler LO semi-rigid
cables when boards are
on extender boards.
SMB Gray Cable (2 ea.) 8120-5020 To extend SMB cables.
MMCX Cable 8120-8866 To measure output jacks
on the A12 synthesizer
assembly.
Miscellaneous Items
SMA “Barrel” 1250-1158 To extend semi-rigid
cables
SMB “Barrel” (2 ea.) 1250-0669 To extend SMBs
SMB Cable Puller 5021-6773
Table 1-2 Agilent Service Kit (Agilent part number E4440-60090)
Agilent Part Agilent Part Number Specifications
