Agilent Technologies E4447A

Chapter 10 243
Replaceable Parts Lists and Locations
Replaceable Parts
W77 Cable (51), coax,
321.4 MHz IF OUT, from
A33 Option card J5 to rear
panel (Option H70)
8121-0705 X X X X X X
W78 Cable, semi-rigid,
FL2 to FL3
(Option 122 or 140)
E4446-20047 X X X X X
W79 Cable, semi-rigid,
FL3 to A20 Lowband
(Option 122 or 140)
E4446-20048 X X X X X
W80 Cable, semi-rigid,
Input Attenuator to
Switch 1 (Option 123)
E4440-20090 X X X
W81 Cable, semi-rigid
(with ferrites),
Switch 1 (bottom switch)
port 2 to RYTHM input
(Option 123)
E4440-20091 X X X
W82 Cable, semi-rigid,
Switch 1 (bottom switch)
port 1 to Mixer input
(Option 123)
E4440-20092 X X X
W83 Cable, semi-rigid,
Mixer LO IN to cable W88
from SLODA LO Out
(Option 123)
E4440-20093 X X X
W84 Cable (1), coax,
Dual Mixer Out to Switch 2
(top switch) port 1
(Option 123)
E4440-60298 X X X
W85 Wire Harness,
FE Driver J11 to
Switches/Mixer
(Option 123)
E4440-60077 X X X
W86 Cable (10), coax,
3rd Converter J1 to
Switch 2 (top switch) port C
(Option 123)
E4440-60373 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
