Agilent Technologies E4447A

Chapter 10 255
Replaceable Parts Lists and Locations
Hardware
Item Description Agilent Part Number
1 J1 Input Connector, Type N 08559-60002
2 A14 Input Attenuator (4 dB)/Switch/Block cap) 33360-60003
3 A15 Input Attenuator (66 dB) 33321-60058
4 L-bracket, RF Main E4440-00001
5 A18 YTO, 2.9 to 7 GHz (Yig Tuned Oscillator) E4440-60023
6 A19 RYTHM, 26.5 GHz (Routing YIG Tuned
Harmonic Mixer)
5087-7070
6 A19 RYTHM, 6.7 and 13.2 GHz 5087-7183
7 A20 Low Band Assembly E4440-60217
8 FL1 Low Pass Filter, 3 GHz 0955-0988
9 A21 SLODA (Switched LO Distribution
Amplifier)
5087-7700
10 FL2 Band Pass Filter, 3.9214 GHz 0955-1074
11 RF Frame E4440-20165
