Chapter 10 303
Replaceable Parts Lists and Locations
Hardware
Figure 10-36 CPU Parts
Item Description
Agilent Part
Number
1 A26A1 128M DRAM Assy (includes replacement
standoffs)
E4406-60053
2 A26A2 64 MB Flash Memory Replacement Kit
(includes replacement standoffs)
E4440-60094
3 A26 CPU (Processor) (includes standoffs; does not
include A26A1 DRAM assy or A26A2 Flash
Memory assy)
E4406-60060
4 Standoffs, Memory boards 0380-4163
5 Screwlock, GPIB .327 x 6-32 0380-0644
6
CPU Plate not replaceable
7 Screwlock, 0.312 x 4-40 0380-1858
8 Nylon spacer .25 round (4 spacers keep the CPU
from bending when vertical boards are inserted)
0380-4662
9 A26BTI Battery, Lithium Polycarbon Monofloride
(3V, 0.16AH Panasonic BR2325)
1420-0314
10 CPU shim E4406-00079
11 CPU shim E4406-00076
