10 User’s Guide
E8362/3/4C Option H85
Specifications: Front Panel Jumpers and Test Ports
Table 9 Frequency Band Crossing
Band Frequency (GHz) Band Frequency (GHz)
E8362/3/4CH85
0 0 to 0.045 14 15.2 to 16.0
1 0.045 to 0.748 15 16.0 to 20.0
2 0.748 to 1.5 E8362/3CH85
3 1.5 to 3.0 16 20.0 to 22.8
4 3.0 to 3.8 17 22.8 to 25.6
5 4.0 to 4.5 18 25.6 to 30
6 4.5 to 4.8 19 30.0 to 32.0
7
4.8 to 6.0 20 32.0 to 36.0
8
6.0 to 6.4 21
36.0 to 38.4
9 6.4 to 7.6 22 38.4 to 40
10 7.6 to 10.0 E8364CH85
11 10.0 to 12.0 23 40.0 to 45.6
12 12.0 to 12.8 24 45.6 to 48.0
13 12.8 to 15.2 25 48.0 to 50.0
