6-14 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Top Cables–All, All Options Except 080
Ref. Desig. Type
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable; nR = n wires in a ribbon (flat) cable
Part Number Qty Description
W19 SR E8364-20027 1
A8 fractional-N synthesizer board J106
to A17 LOMA 10 J2
W20 SR E8364-20057 1
A8 fractional-N synthesizer board J101
to A17 LOMA 10 J3
W25 F E8364-60126 1
A6 SPAM board J3
to A31 receiver A J400
W26 F E8364-60127 1
A6 SPAM board J4
to A32 receiver R1 J400
W27 F E8364-60128 1
A6 SPAM board J5
to A33 receiver R2 J400
W28 F E8364-60129 1
A6 SPAM board J6
to A34 receiver B J400
W29 F E8364-60124 1
A10 frequency reference board J4
to A35 receiver motherboard J2
W30 F E8364-60125 1
A11 phase lock board J6
to A35 receiver motherboard J50
W31 F E8356-60052 1
A10 frequency reference board J10
to A8 fractional-N synthesizer board J105
W32 F E8356-60043 1
A10 frequency reference board J5
to A11 phase lock board J5
W33
F 8120-5055
1
A10 frequency reference board J2
to rear-panel 10 MHz REF. IN
W34 1
A10 frequency reference board J3
to rear-panel 10 MHz REF. OUT
➀
40R 8121-0116 1
A3 front panel interface board
to A14 system motherboard
➁
6W 8121-0932 1 USB hub to A14 system motherboard
