Agilent Technologies E8363B User Manual

6-62 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Bottom Semi-Rigid Cables, Options UNL/014/016/080/081/H11
Ref. Desig. Models Part Number Qty Description
W2 E8363B, E8364B E8364-20034 1 A21 SOMA 50 to A22 switch splitter
W3
E8362B E8362-20003
1
A22 switch splitter to channel R1 30-dB attenuator
E8363B, E8364B E8364-20144 A22 switch splitter to A23 detector
W4
E8362B E8362-20004
1
A22 switch splitter to channel R2 30-dB attenuator
E8363B, E8364B E8364-20024 A22 switch splitter to A24 detector
W11 All E8364-20171 1 A20 LODA to A27 channel A mixer
W12 All E8364-20172 1 A20 LODA to A28 channel R1 mixer
W13 All E8364-20173 1 A20 LODA to A29 channel R2 mixer
W14 All E8364-20146 1 A20 LODA to W40 (to A30 channel B mixer)
W15 All E8361-20056 1 A19 splitter to A20 LODA
W16 All E8361-20057 1 A19 splitter to A20 LODA
W18 All E8364-20145 1 A17 LOMA 10 to A18 MA 20
W19-W20 All
Refer to “Top Cables–All, All Options Except 080” on page 6-14
.
W40 All E8364-20032 1 W14 (from A20 LODA) to A30 channel B mixer
W47 All E8364-20131 1 A43 channel A step attenuator to A27 channel A mixer
W48 All E8364-20132 1 A44 channel B step attenuator to A30 channel B mixer
W49
E8362B E8362-20035
1 A IN to A43 channel A step attenuator
E8363B, E8364B E8364-20129
W50
E8362B E8362-20036
1 B IN to A44 channel B step attenuator
E8363B, E8364B E8364-20130
W51 All E8364-20055 1 A22 switch splitter to A36 step attenuator
W52 All E8364-20056 1 A22 switch splitter to A37 step attenuator
W55 All E8364-20167 1 A38 bias tee to A25 test port 1 coupler
W56 All E8364-20168 1 A39 bias tee to A26 test port 2 coupler
W60
E8362B 08720-20098
6 Front-panel jumper
E8363B, E8364B E8364-20059
W66
E8362B E8362-20053
1
Channel R2 attenuator to channel R2 SOURCE OUT
E8363B, E8364B E8364-20048 A24 detector to channel R2 SOURCE OUT
W67
E8362B E8362-20051
1 A25 test port 1 coupler to Port 1 CPLR ARM
E8363B, E8364B E8364-20156
W68
E8362B E8362-20052
1 A26 test port 2 coupler to Port 2 CPLR ARM
E8363B, E8364B E8364-20157
W71
E8362B E8362-20038
1 R2 IN to A29 channel R2 mixer
E8363B, E8364B E8364-20126
W81
E8362B E8362-20024
1 A36 step attenuator to port 1 SOURCE OUT
E8363B, E8364B E8364-20053
W82
E8362B E8362-20025
1 A37 step attenuator to port 2 SOURCE OUT
E8363B, E8364B E8364-20054
W83
E8362B E8362-20012
1 Port 1 CPLR THRU to A38 bias tee
E8363B, E8364B E8364-20039
W84
E8362B E8362-20013
1 Port 2 CPLR THRU to A39 bias tee
E8363B, E8364B E8364-20040
W95
E8362B E8362-20032
1
A46 reference switch to channel R1 attenuator
E8363B, E8364B E8364-20119 A46 reference switch to A23 detector
W96 All E8364-20127 1 A45 reference switch to A46 reference switch
W97
E8362B E8362-20033
1 A46 reference switch to REF SOURCE OUT
E8363B, E8364B E8364-20121
W98
E8362B E8362-20034
1 A45 reference switch to REF R1 IN
E8363B, E8364B E8364-20123
W99
E8362B E8362-20037
1 A45 reference switch to A28 R1 mixer
E8363B, E8364B E8364-20125
W109 All E8361-20050 1 A12 source to A47 RF coupler
W110 All E8361-20053 1 A18 MA 24 to A48 LO coupler
W111
E8362B E8362-20055
1
A47 RF coupler to A22 switch
E8363B, E8364B E8361-20051 A47 RF coupler to A21 SOMA 50
W112 All E8361-20055 1 A48 LO coupler to A19 splitter
W113 All E8361-20052 1 A47 RF coupler to rear panel TEST SET DRIVERS RF
W114 All E8361-20054 1 A48 LO coupler to rear panel TEST SET DRIVERS LO
