6-80 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Miscellaneous Part Numbers
Table 6-3 Part Numbers for Miscellaneous Parts and Accessories
Description
Model or Part
Number
Service Tools
Extender board, synthesizer/reference E8356-60021
20-mm open-end torque wrench (included with analyzer); 0.9 N-m (8 in-lb) 8710-1764
1/4-in and 5/16-in open-end wrench, thin profile 8710-0510
5/16-in (8 mm), open-end torque wrench; 0.9 N-m (8 in-lb) 8710-1765
Spanner wrench 08513-20014
Documentation
Installation and Quick Start Guide (for all PNA series analyzers) (Cannot be ordered. Part
number is for reference only. Must be printed from the Agilent Web site. Refer to “Printing
Copies of Documentation from the Web” on page iv.)
E8356-90001
Service Guide (Not available in printed form. Part number is for reference only. Must be
printed from the Agilent Web site. Refer to “Printing Copies of Documentation from the
Web” on page iv.)
E8364-90026
Protective Caps for Connectors
Front panel jumper guard E8361-00009
Protective cap for GPIB connector
1252-5007
Protective cap for Test Set I/O connector 1252-1935
Protective cap for Aux I/O connector 1252-4691
Protective cap for Handler I/O connector 1253-5320
Protective cap for Display (VGA) connector 1252-3422
Protective cap for Serial (RS-232) connector 1252-0220
Protective cap for Parallel (1284-C) connector 1252-1935
Protective cap for Test port (Port 1, Port 2) connector (E8363B, E8364B) 1401-0247
GPIB Cables/GPIB Adapter
GPIB cable, 0.5 meter (1.6 feet) 10833D
GPIB cable, 1 meter (3.3 feet) 10833A
GPIB cable, 2 meter (6.6 feet) 10833B
GPIB cable, 4 meter (13.2 feet) 10833C
GPIB cable to GPIB cable adapter 10834A
Battery
Battery, lithium, 3V, .22A-HR (located on the A15 CPU board)
1420-0356
To Next Page
