Agilent Technologies ENA Series

Product Declassification and Security Product Name: ENA series RF Network Analyzer
Model Number(s): E5071C
Page 5 of 9
Memory Clearing, Sanitization and/or Removal Procedures
This section explains how to clear, sanitize, and remove memory from you instrument for all memory that can be
written to during normal operation and for which the clearing and sanitization procedure is more than trivial such as
rebooting your instrument.
<Memory type>
Description and
purpose
Main Memory (RAM) 1GB for Windows Operating system memory
Size
1GB
Memory clearing
Power rebooting. This is a volatile memory.
Memory sanitization
Power rebooting. This is a volatile memory.
Memory removal
This memory can not be removed without damaging the instrument
Write protecting
N/A
Memory validation
N/A
Remarks
Description and
purpose
Media Storage (Built-in Hard Disk) for Windows Operating system boot device,
factory correction data, service log, and users file including saved traces data,
settings, or images.
Size
40 GB (Only 20 GB is used in E5071C)
Memory clearing
N/A
Memory sanitization
N/A
Memory removal
Built-in hard disk is removable. Refer to the below note for the detail information
for remove/replace/re-store the disk.
Write protecting
N/A
Memory validation
N/A
Remarks
Hard Disk removal: Because it is virtually impossible to completely and selectively erase all user data on a hard drive without
also destroying the operating system, the best method for maintaining security when the ENA must be removed from a secure
area is to replace the hard drive with a "non-secure" hard drive, i.e. a drive that has never had any sensitive data placed on it. This
allows the ENA to still function properly in non-secured areas or for use when servicing.
E5071C-017 has an easily accessible hard drive on the front panel. Agilent has available a relatively inexpensive, pre-configured
hard drive for the ENA that must be purchased in order for this security method to work. An spare disk is available as E5071CU-
018.
For Option 019 User:
Before taking the following steps, Option 019 user must be applied the E5071CU-017 (UPGADE TO REMOVABLE HARD
DISK DRIVE).
Hard disk removal: Step-by-step procedure
these steps should be followed to maintain security:
1. Purchase the Hard Disk Drive Kit (E5071CU Option 018). A new hard disk is not included in this option and an
original disk is reused. Order E5071CU-018 if spare disk is necessary.
2. Clearly mark this hard drive as "Unsecured!". In the event the secure ENA needs to be used elsewhere, or, if it needs
servicing:
3. Copy the files with .lic extension into your USB memory (or network shared directory). The files have option
information.
