Chapter 4 51
Viewing Catalogs and Saving Files
File Menu Functions
File Menu Functions
This chapter describes how to use the functions located under the front-panel File key. Data storage and
retrieval are handled similarly to that of personal computers (PCs). Like PCs, these analyzers include an
internal storage drive and a floppy disk drive, both of which have directory and sub-directory capability.
NOTE The descriptions in this section assume the analyzer has firmware revision A.04.00 or
later. The file menu functions in earlier firmware are different. If you would like to
upgrade your analyzer to the latest firmware revision, please visit the following web site:
http://www.agilent.com/find/esa
You will learn how to do all of the following:
• locate and view files in the catalog
• create a directory
• format a floppy disk
• save a file
•load a file
• rename a file
• copy a file
• delete a file
NOTE The display examples in this book are made using various analyzer models, you may see
some variations depending upon your analyzer.
Locating and viewing files in the catalog
Techniques for locating files and directories are consistent throughout the various file menu functions.
Although this section provides specific information about navigation in the catalog, you may wish to
refer back to this section when performing other operations of the file menu.
The analyzer has three default catalogs (directories):
• State, which stores analyzer settings.
• Trace, which stores trace information.
• Screen, which stores screen captures of the display in .gif or .wmf format.
NOTE Trace files are not bitmap files. Files saved as Trace cannot be imported into other
applications or converted. If you require the use of other applications, for example
Microsoft‚ Word or Microsoft‚ Excel, be sure to save your files as .gif or .wmf formats
using Screen for your file Type.
