RF Output
Maximum Leveled Output Power (0% to + 35%):
Frequency Standard with Option 1El
l-20 GHz + 11 dBm
+lOdBm
18
F
4 8 12 16 20
Carrier Frequency (GHz)
Figure l-l.
Typical Maximum Available Output Power from 1 to 20 GHz, at 25°C with Output Step
Attenuator (Option 1El) Installed
Bfinimum Leveled Output Power (without Option 1El):
OdBm
Minimum Leveled Output Power (with Option 1El):
-110 dBm (-90 dBm on HP 83711A)
Display Resolution:
0.01 dB
Accuracy:
f1.0 dB (over all power levels)
(0 dBm to specSed maximum leveled output power)
f2.0 dB (power > -90 dESm)
f2.5 dB (power < -90 dBm
The use of Type-N RF’ connectors above 18.0 GHz degrades specijkation typically by 0.2 dB.
Flatness:
f0.5 dB (power L-90 dBm)
f0.7 dB (power c-90 dBm)
The use of Type-N RJ? connectors above 18.0 GHz degrades speci&ation typically by 0.2 dEI.
Level Switching Time: ~17 ms (without step attenuator range change).
Attenuator Range Changes Occur At:
HP83711l!$ HP 83712B -1 d&n., -11 dBm, -21 dBrn, etc)
outm SWR <2.0: 172um~na1
HP 83711A/l1B8pecificetions 13
