Maximum Pulse Repetition l+-m: > 3 MHk
Minimum Pulse Duty Cz/cle: No restrictions on duty cycle
Pulse L4mel Accuracy Al.0 OTB (relative to CW)
Pulse &.wr&oot: < 10%
Input Impedance: 5OQ nominal; llZ drive levels
Maximum Leveled Output Rrwer in Pulse Mode: -0.5 dB relative to CW
Timebase = 10.0 ns/div Risetime = 4.9 ns
Carrier Frequency = 10.0 GHz Falltime = 2.05 ns
Figure 1-28.
pk6l Oab
Typical Pulse Modulation Envelope Illustrates the Fast Rise and Fall Times, Excellent
Flatness and Pulse Fidelity
HP 83731 B/328 Specifications
l-27
