Internal Pulse Source
Pulse Source Modes:
Pulse Repetition kequency:
Pulse Repetition Interval
(PRI):
Pulse Width (T,):
Variable Pulse Delay (free-run
mode, Td):
Variable Pulse Delay
(triggered with delay &
doublet modes, Td):
Pulse Width/Delay/PRI
Resolution:
Pulse Delay (Vi& to Rl$ T,):
Free-run, triggered with delay, doublet and gated. Triggered
with delay, doublet and gated require external trigger source.
3Hzto>3MHz
300 ns to 419 ms
25 ns to 419 ms
f419 ms from synchronizing pulse to video output.
225 ns to 419 ms with k25 ns jitter
25 ns
Norninull~ <20 ns, 1 to 20 GHz
All pulse modulation specifications and supplemental characteristics apply during use of
internal pulse source.
Td Video Delay (Variable) Tr RF Pulse Rise Time
T, Video Pulse Width (Variable)
Tf RF Pulse Fall Time
T,, Pulse Period (Variable)
Vor Overshoot and Ringing
T,,, RF Delay
Vf Video Feethrough
Trf RF Pulse Width
l-28 HP83731Bj328Specifications
