Agilent Technologies IDP-7

IDP-7 Dry Scroll Vacuum Pump
14
DRAFT 1/19/17
Start Current
Table 3 lists the typical IDP-7 maximum starting current
and duration.
Table 3 Typical IDP-7 Maximum Starting Current (A)
Frequency High Voltage Range
100 V 120 V 127 V 200 V 230 V 240 V
60 Hz
22 25 25 12 N/A 14
50 Hz
23 N/A N/A 12 14 15
