IDP-7 Dry Scroll Vacuum Pump
18
DRAFT 1/19/17
Maintenance
Kits and Service Options
Service of the IDP-7 should be performed by properly
trained personnel only.
Agilent pumps will provide many years of trouble-free
service if the maintenance procedures and intervals are
observed. Cleaning and tip seal replacement are recom-
mended when pump base pressure has risen to an unac-
ceptably high level for your application. If your pump
exhibits humming or grinding noises from the bearings, a
major overhaul should be done by Agilent or an autho-
rized rebuild center. Advance exchange pumps are avail-
able to minimize downtime.
The parts needed for tip seal replacement on the IDP-7
are available in the kit described in Table 5. This kit con-
tains seals and O-rings, and can be obtained from your
Agilent dealer.
Service
Agilent offers rebuilding service at our repair centers, or
you can obtain advance exchange of complete IDP-7
pumps. The service plans available and their ordering
numbers are given in Table 6.
Cleaning
Exterior
The exterior surfaces of the IDP-7 may be cleaned with a
cloth slightly moistened with water. If necessary alcohol
or a mild detergent may be used instead. Do not pour or
spray any liquids onto the pump.
Interior
Run the pump periodically at atmosphere for a minute or
two to flush it out. For more information, see “Cleaning
the Pump” on page 16.
Tip Seal Replacement
The parts and tools required to replace tip seals include:
❑ Tip Seal Replacement Kit P/N X3807-67000
❑ 4 and 8 mm Allen wrenches
❑ Razor blade or side-cutting pliers
❑ Compressed air (optional)
Figure 7 on page 19 shows the various components
involved in a tip seal replacement procedure. Refer to
Figure 7 as you follow the procedure.
To remove the worn tip seals:
1. Disconnect the pump from electrical power.
2. Remove (3) M8 socket head bolts (item 1).
Table 5 Accessories and Replacement Kits
Part
Number
Description Contents
X3807-67002 Front Cowling
Assembly
Replacement front
cowling material to
replace a broken
plastic cowling.
X3807-67003 Rear Cowling
Assembly
Replacement rear
cowling material to
replace a broken
plastic cowling.
X3807-68008 Gas Ballast Kit Spare Parts
NOTE For further service options, please con-
tact your local service center listed in
the back of this manual and ask for your
local representative.
Table 6 Service Options
Factory Service Plans Model Number
Replacement Tip Seal Set X3807-67000
IDP-7 Exchange Pump
X3807-69000
IDP-7 Exchange with Inlet Valve
X3807-69010
IDP-7 Full Pump Rebuild X3807-69000-RP
IIDP-7 Full Pump (with inlet
valve) Rebuild
X3807-69010-RP
WARNING If dangerous gases were being pumped,
flush the pump with air or inert gas for
at least 10 minutes prior to disassembly.
