1Getting Started
26 N1913/1914A Installation Guide
Auto IP Mode
Use this procedure if you require local PC Control or you are working in
an isolated (non- site) LAN.
1 Connect the computer to the power meter.
2 Switch the power meter on.
3 Press ,
Remote Interfaces to display the Remote Interface display
(see Figure 1- 2). Ensure that AutoIP is checked.
4 Press
Network AutoIP if you need to set any optional settings.
5 Press
Restart Network.
A pop- up appears for 5 seconds (see Figure 1- 3). Monitor the Status at
the bottom of the display to see when the server has assigned an
address.
6 Press , to return to a measurement screen.
7 If you intend to program over LAN or use such programs, make sure
you have installed I/O software on your PC.
8 Use the Connection Expert utility of the IO Libraries Suite to add the
power meter and verify a connection.
9 You can use various programming environments to control the power
meter. For an overview about programming instruments via LAN, refer
to the connectivity guide.
If you have installed other I/O software, refer to documentation that accompanies the
software.
