Vector Modulation Analysis
(Option 89601A-AYA)
Note that analysis and presets are
only valid over the frequency range
of the N4010A-101/102.
Signal acquisition
Note: Signal acquisition does not require
an external carrier or symbol clock
Data block length Adjustable to 4096 symbols
Samples per symbol 1 – 20
Symbol clock Internally generated
Carrier lock Internally locked
Triggering Single/continuous, external, pulse search
(searches data block for beginning of TDMA burst
and performs analysis over selected burst length)
Data synchronization User-selected synchronization words
Supported modulation formats
Carrier types Continuous and pulsed/burst (such as TDMA)
Modulation formats 2, 4, 8, and 16 level FSK (including GFSK)
MSK (including GMSK)
QAM implementation of BPSK, QPSK, OQPSK,
DQPSK, D8PSK, π/4DQPSK, 8PSK,
3
π
8PSK (EDGE)
8
16QAM, 32QAM, 64QAM, 128QAM, 256QAM
(absolute encoding)
16QAM, 32QAM, 64QAM
(differential encoding per DVB standard)
8VSB, 16VSB
Single-button presses for
Cellular CDMA (base), CDMA (mobile), CDPD, EDGE, GSM,
NADC, PDC, PHP (PHS), W-CDMA
Wireless networking Bluetooth, HIPERLAN/1 (HBR), HIPERLAN/1 (LBR),
802.11b
Digital video DTV8, DTV16, DVB16, DVB32, DVB64
Other APCO 25, DECT, TETRA, VDL mode 3
Filtering
Filter types Raised cosine, square-root raised cosine, IS-95
compatible, Gaussian, EDGE, low pass, rectangular,
none
Filter length 40 symbols: VSB, QAM, and DVB-QAM where
α < 0.2
User selectable alpha/BT Continuously adjustable from 0.05 to 10
User-defined filters User-defined impulse response,
fixed 20 points/symbol
Maximum 20 symbols in length or 401 points
10
