Equalizer measurement results
Equalizer impulse response Computed from preamble
Channel frequency response Computed from preamble
Pre-demodulation measurement results
Time Instantaneous
Spectrum Instantaneous, average
Search time Instantaneous
Display formats
Error vector spectrum Error values for each symbol time plotted for each
carrier
Error vector time Error values for each carrier plotted for each
symbol time
Accuracy (nominal)
Residual EVM < 2% rms
Residual constellation error –34 dB
Frequency error (relative to frequency standard)
Lock range ±624 kHz (±2 x sub-carrier spacing)
Accuracy 1 kHz
15
