Demodulation measurement results
IQ measured IQ measured time, IQ measured spectrum,
instantaneous IQ measured spectrum
IQ reference IQ reference time, IQ reference spectrum,
instantaneous IQ reference spectrum
Other IQ error traces IQ magnitude error, IQ phase error
Error vector Error vector time, error vector spectrum,
instantaneous error vector spectrum
Despread symbols Preamble, header, data
Symbol and error table summary 802.11b 1,000-chip peak EVM, EVM, magnitude
error, phase error, IQ offset, frequency error, sync
correlation, burst type, bit rate, number of data
octets, data length
Equalizer measurement results
Equalizer impulse response Computed from preamble
Channel frequency response Computed from preamble
Pre-demodulation measurement results
Time Main raw, search
Spectrum Instantaneous
Other CCDF, CDF, PDF
Display formats
Error vector spectrum Error values for each symbol time plotted for each
carrier
Error vector time Error values for each carrier plotted for each
symbol time
Accuracy (nominal)
Residual EVM ≤ 2 % rms
Frequency error (relative to frequency standard)
Lock range ±2.5 MHz
Accuracy 1 kHz
17
