Touchscreen menus and commands
G5585B PlateLocThermal Microplate Sealer Quick Guide
Preset page
Figure Example of Preset edit page
Control or indicator Description
Preset 01 — 10 Displays the list of saved plate sealing methods that you
can use.
Note: By default, the recommended starting point settings
for different seal and microplate types are stored as
Presets 01–06. For the most up-to-date starting point
settings, see the Seal Selection Guide.
Edit Displays the Preset edit page where you can modify the
seal time and temperature values for a highlighted preset.
Press or to highlight the desired row in the table.
Select Loads the settings of the highlighted Preset row to the
Home page.
