395411000: Rev. 5 3 of 14 Pre-installation Instructions
Before the Installation
User Representative
Schedule the installation when the User Representative will be available. One of the important
duties of the Varian Representative is to familiarize the User Representative with the basic
functions of the LC/MS.
;
Check off the checklist box: User Representative will be available during the
installation and Varian certification period.
Entrance
Before arranging delivery of the LC/MS, determine that there is sufficient clearance to move the
shipping cartons to the installation site. The largest shipping carton is 72 cm (28 in.) wide by 92
cm (36 in.) long. If the cartons are to be moved with the pallet, at least 92 cm (36 in.) clearance
is needed. Allow additional room for maneuvering the shipping containers around corners and
through doors.
;
Check the checklist box: Entrance to the installation site is at least 92 cm (36 in.).
CAUTIO
The MS, foreline pump(s), and LC are heavy. To prevent
personal injury, use appropriate moving and lifting
techniques.
Bench Space and Load
Use the following information to plan the layout of your LC/MS. The Varian Representative will
unpack the cartons and put the modules on the bench. Although the figures show a 320-MS,
the information also applies to a 310-MS.
Figure 1 and Figure 2 show suggested layouts for the LC/MS with the 212-LC and different
autosamplers.
The tables after the figures provide information about bench space and load. The bench must
be strong enough to support the weight of all modules, wide enough for all modules, and at
least 84 cm (33 in.) deep for the MS.
