395411000: Rev. 5 9 of 14 Pre-installation Instructions
310/320-MS LC/MS
The 310/320-MS LC/MS requires the following:
Table 9 301/320-MS LC/MS Circuits, Power Plug and Outlet Types
Table 9 lists the circuits, power plug and outlet types of the 310/320-MS LC/MS.
Component Circuit Power Plug and Outlet type
MS 1 each 220V US: 1 each NEMA 6-15P
EU: 1 each CEE 7/7 plugs
Foreline pump 2 each 220V US: 1 each NEMA 6-15P
EU: 1 each CEE 7/7 plugs
Computer 1 each 110V US: 1 each NEMA 5-15P
1 each 220V US 1 each NEMA 6-16P
EU: 1 each CEE 7/7 plugs
LC modules 110V or 220V see appropriate user manual
Table 10 has the power requirements for modules of the 310/320-MS LC/MS.
Table 10 LC/M
S Power Requirements
Module Max Current Draw (Amps)
200-240V ac
320-MS or 310-MS 5
Foreline pumps
5 per pump
Use a separate dedicated power source for HPLC modules and additional instruments and
equipment. Never plug the mass spectrometer and the chromatograph into the same power
source or the power source may overload. Never use the free outlet on any of the power
sources for equipment that draws more than 2A.
Table 11 has information about the power cords and plugs.
Table 11 M
S and Foreline Pump(s) Power Cords
Module 500-MS Foreline Pump(s)
Power Cord 1 each 2.5 m (8 ft) 2 each 2.0 m (6 ft 7 in.)
Power Plug 1 each CEE 7/7 plugs 2 each CEE 7/7 plugs
The power cables for the CPU, monitor, and printer are approximately 2.13 m (7 ft) long.
Figure 3 shows the power plug and outlet types.
CAUTIO
Replacing or substituting power cords or plugs must be done
with strict compliance with all regulations, including
electrical codes, power cord color coding, and appropriate
regulatory agency certification marks.
