5 SPECIFICATIONS
5.1 SPECIFICATIONS
TABLE 5-1. SYSTEM DATA
ITEM
ASP
TM25-336
ASP
TM25-640
ASP
TM50-336
ASP
TM50-640
ASP
TM75-336
ASP
TM75-640
Optical Magnification 1.6× 1× 2.9× 1.7× 4.3× 2.6×
Objective Lens Type Germanium
Type of Focal Plane Array FLIR Tau 2
Frame Rate 60 Hz 30 Hz 60 Hz 30 Hz 60 Hz 30 Hz
Pixel Array Format 336×256 640×512 336×256 640×512 336×256 640×512
Pixel Size 17 µm
Pixel Display Format 800×600
Display Brightness Discretely Adjustable to 8 Levels
Turn-on Time, max 3 sec
Digital Zoom 2×, 4× 2×, 4×, 8× 2×, 4× 2×, 4×, 8× 2×, 4× 2×, 4×, 8×
Temperature Imaging Modes
(Image Palettes)
White Hot, Black Hot, Fusion, Rainbow, Globow, Ironbow 1,
Ironbow 2, Sepia, Color 1, Color 2, Ice-Fire, Rain, and OEM
Analog Video Input/ Output
Format (resolution)
PAL (768×574 pixels)
/ NTSC (640×480 pixels)
Interfacing
• Micro-USB (Power bank 5V)
• Universal S620 connector (Power In, Analog Video In/Out,
Wi-Fi Attachment, HD Recorder, Extended Battery Pack)
TABLE 5-2. OPTICAL DATA
ITEM
ASP
TB25-336
ASP
TB25-640
ASP
TB50-336
ASP
TB50-640
ASP
TB75-336
ASP
TB75-640
Field of
View
- ang. X degrees 12.6 24 7.8 14.8 4.3 8.3
- ang. Y degrees 10 20 5.9 11.8 3.2 6.6
Objective Focal Length 25 mm 50 mm 75 mm
Objective F-number 1:1 1:1 1:1
Exit Pupil Diameter 14mm
Eye Relief 16mm
Focus Method Manual
Focusing Range 5m to inf.
Diopter Adjustment Manual
Diopter Adjustment Range ±5 diopter
