F14 USER MANUAL 23
5 SPECIFICATIONS
5.1 SPECIFICATIONS
ITEM DATA
Detector Type 12 μm VOx Uncooled Focal Plane Arrays
Resolution 640×512
Refresh Rate 50 Hz
Response Waveband 8 μm to 14 μm
Thermal Lens Focal Length 16 mm
Thermal Field of View (HxV) 25.8° × 19.1°
Digital Zoom 1x, 2x, 4x, 8x
Observation Distance 1,500 m (human detection)
Flat Field Correction (FFC) Manual
Palettes
White Hot/Black Hot/Orange Hot, Outline,
Highlighting, Thermal Image, Breath
Video Output Yes (via aviation plug)
I
2
Night Vision Sensor Gen 2+ or Gen 3 Image Intensifier Tube
I
2
Night Vision Module
Manual Gain Control
Yes
I
2
Night Vision Module
Lens Focal Length
25 mm
I
2
Night Vision Module
Field of View
40°
Optical Magnification 1x
Diopter Adjustment - 3.5 ... + 2.5
Exit Pupil Diameter 15 mm
Eye Relief 25 mm
Bright Light Cut-Off Yes
Infrared Illuminator Yes
Battery Type Two 18650 rechargeable Lithium battery
Battery Operating Time
- More then 8 hours continuous running
(fusion image mode)
- More then 60 hours continuous running
(I
2
night vision only)
Battery Capacity Display Yes
External Power 5 VDC/2 A (via aviation plug)
Working Temperature -40°C to 60°C (-40°F to 140°F)
Protection Level IP67 (Waterproof)
Dimensions 100 × 71 × 86 mm (3.9 × 2.8 × 3.4 in)
Weight (w/o batteries) 380 g (0.84 Ib)
*
All data subject to change without notice.
