F14 USER MANUAL 7
TABLE 1-1. MAIN PARTS
ITEM DESCRIPTION ITEM DESCRIPTION
1 Objective lens hood 7 I
2
switch/Adjusting knob
2 I
2
objective lens 8 Fill-in light switch
3 Quick removal interface 9
Infrared switch/
Adjusting knob
4 Device body 10 Infrared objective lens
5 Ocular lens 11 Infrared lens hood
6 Eye cup 12 Aviation plug
1.2 STANDARD COMPONENTS
The standard components are shown in Figure 1-2 and listed in Table 1-2.
The ITEM NO. column indicates the number used to identify items in Figure 1-2.
TABLE 1-2. STANDARD COMPONENTS
ITEM DESCRIPTION QUANTITY
1 Monocular 1
2 Battery holder 1
3 Helmet support 1
4 Battery holder interface with hook-loop support 1
5 18650 rechargeable Lithium battery 2
6 Eye cup 1
7 Video cable 1
8 Operation manual 1
9 Packing case 1
FIGURE 1-2. STANDARD COMPONENTS
8
9
2 3 4 51
6
7
