KEY DESCRIPTION QTY
A Display Unit/Electronics Module 1
A-1 Mounting Bracket 1
A-2 Mounting Knobs 2
B 10’ Power Cable with 2 Amp Fuse 1
(Automotive Blade Type) in Fuse Holder
C 35’ (10.6m) Shielded Sensor Cable 2
C-1 Plastic Cable Ties 12
D Sensor Pad Kits 2
D-1 4mm X 30mm Stainless Steel Bolt 8
D-2 4mm Stainless Steel Lock Washer 12
D-3 4mm Stainless Steel Nut 12
D-4 Plastic Washer 4
D-5 Plastic Insulator 4
D-6 Sheet Metal Screw, Self Tapping, Phillips 2
(Use with Mounting Bracket)
D-7 Sensor Pad 2
D-8 Drilling Template 2
Set Up and Installation
2
A-1
A-2 D-1 D-2 D-3 D-4 D-6D-5
D-7 D-8
To Next Page
