TESTER COMPONENTS
The BHT-2 is comprised of a display module with mounting bracket at-
tached by 2 knobs (A), a 10’ fused power cable (B), two 35’ shielded sen-
sor cables with 12 cable ties (C), two moisture sensor kits with mounting
hardware and drilling templates (D), and one USB cable (E). Identify all
parts listed in the table below before beginning installation.
Set Up and Installation
A
B
C
D
E
1
C-1
