CONVENTIONAL SQUARE BALER
Rear
Side View of Bale Chamber End View of Bale Chamber
Both Sensors Mounted
Knotter
Assembly
Sensor Pad
Sensor Pad
Sensor Pad
Halfway
12”-24”
Set Up and Installation
5
OPTIMUM
SENSOR
LOCATION
